2-15bar Low Pressure Piston air Compressor 360-3000m3/hr
Model：SZV,SZD
Data range：2-15bar
Low Pressure Oil Free air Compressor
Oil-free deign, meeting class 0 standard
1 stage or 2 stage compression ,2-15bar pressure
Long life, low maintenance cost
Oil-free deign, meeting class 0 standard
1 stage or 2 stage compression ,2-15bar pressure
Long life, low maintenance cost
Technical Parameter:
|
Model |
FAD |
speed r.p.m |
Moto Power KW |
Note
|
|
|
m3/min |
cfm |
||||
|
SZV-6/10 |
6.5 |
212 |
485 |
37 |
V-type 2-column 2-stage |
|
SZV-8/10 |
8.5 |
282 |
645 |
55 |
|
|
SZV-10/10 |
10.5 |
353 |
590 |
75 |
|
|
SZV-12/10 |
12.5 |
441 |
710 |
75 |
|
|
SZD-16/10 |
16.0 |
565 |
440 |
110 |
D-type 2-column 2-stage |
|
SZD-18/10 |
18.0 |
635 |
495 |
132 |
|
|
SZD-20/10 |
20.0 |
706 |
550 |
132 |
|
|
SZD-25/10 |
25.0 |
883 |
600 |
160 |
|
Note：
1、Performance parameters measured according to ISO1217, reference conditions: inlet temperature 20 ℃, inlet air pressure 1barA;
2、Special specifications can be customized.
